Bobcat T870 Undercarriage Parts
Price range: $299.00 through $579.00
-
Priced per part. Each option names the serial range letters it fits.
Which range is my machine? Find your serial number here, then pick the parts marked with that range letter.
| Range | Configuration | Serial numbers (as KTSU lists them) |
|---|---|---|
| Range A | Suspension Mount | A3PG11001 > ABOVE; A3PH11001 > ABOVE; AN8L11001 > ABOVE; ATF811001 > ABOVE; ASWT11001 > ABOVE; B3BZ11001 > ABOVE |
| Range B | Torsion Suspension | B47C11001 > ABOVE, B47H11001>, B47L11001> |
KTSU-made rollers, idlers and sprockets for the Bobcat T870, priced per part.
Parts by range
Serial numbers for each range are in the table above the part picker.
| Range | Drive Sprocket | Front Idler | Rear Idler | Idler | Track Roller |
|---|---|---|---|---|---|
| Range A Suspension Mount |
7165109 (5.75in Inner Depth (6 BH, 1 spd)) 7196807 ((8 BH, 2 spd)) KTSU lists 2 — confirm the spec before ordering |
6698048 (50mm Shaft) | 6698049 | — | 6698047 |
| Range B Torsion Suspension |
7227421 (8BH/17T) | — | 7276596 (Single Flange) | 7276595 (Dbl Flg) | 7323310 (7/8xUC9x2-1/2 In Mtg Bolt) |
KTSU part numbers on this page: 7165109, 7196807, 7227421, 6698048, 6698049, 7276596, 7276595, 6698047, 7323310.
Verify your OEM part number against your serial plate before ordering.
Need tracks? Bobcat T870 Tracks.
